This is a 3D Assembly Model (.stp format) of a pair of LH and RH Interpart Lift Louvre Lock Assemblies. The assembly contains individual part models of the lock components. These plastic locks are no longer available so I hoping that these files will be of use to someone that needs to make replacements. This model was created using Solid Edge ST5. Also included is 3D pdf file of the same assembly for those that don't have a cad program and simply would like to view the model, it requires Adob
