FREE full-color wiring diagram for 1976 280z

[saridout]

well, after weeks of working on it, i'm finally done. and you can reap the benefits of all my work! below i've made available my new, full-color version of the 1976 280z wiring diagram. it is vector-based, so it can be blown up as big as you'd like without losing legibility. the text is copyable and searchable.

i will warn you, i'm 110% sure that there are errors. you get a gold star if you point them out to me. a wire or object in hot pink denotes that i'm not sure of the true color of the item. i'll post updated versions on this thread as needed, so look at the most recent reply for the newest download.

enjoy!

download here: http://sridout.com/datsun/76circuit_COLOR v.1

edit: i thought i'd add an illustration that i just finished for Tim280z of his car. take a look at the thumb below...

Edited November 16, 2009 by saridout
adding image

[260zCaliCar]

That's amazing! That only took "weeks"???

I didn't know the '76 had a 4 wire drivers side door switch, my 74 has 3. In all my searching for a replacement, I never saw a 4 wire version.

[saridout]

thank you i hope it helps everyone as much as drawing it has helped me.

[Ronaldo1973]

Weeks and weeks! Wow that is hard job, you have to sell it on ebay and make money out of it, your job is awesome, and you deserve the money.

I just bought a good full color laminated wiring diagram (14'' X 25") for $19, and that is for my 72 zcar (loved the colored diagram)

Thanks for sharing

[Mikes Z car]

What program did you make the diagram with? It looks great.

Mike

[Z CAR 77]

Huge thanks for all your hard work on this! Now my tired old eyes won't have the strain to read a tiny little diagram in the service manual :classic:

[Zed Head]

Hello. I'm new here but I really could have used this two weeks ago. It looks fantastic, and I second the comment about eye strain. Mine are still sore from trying to figure out how the mechanical voltage regulator was wired.

The color coding is great, and you've gone better than the FSM also by adding color to the fusible links. But I see that you show two red links under the two covers instead of two brown ones. The labeling on the side of my 76 fusible link holders definitely says B, G, and two Br, and the manual says that B, G and Br are used also (page BE-6).

I've seen some discussion around the internet that maybe the brown is really red and you should just use red ones, but my reading leads me to believe that the brown links are real, at 0.3 mm ^2 in size, just not used on many models and not as readily available as the other ones.

Can anyone comment on this? And thanks again for the diagram and I'm glad I have the car it comes from.

Bob

[saridout]

Weeks and weeks! Wow that is hard job, you have to sell it on ebay and make money out of it, your job is awesome, and you deserve the money.

i thought about selling it... i may print and laminate some big ones to sell on ebay eventually. thanks

[saridout]

What program did you make the diagram with? It looks great.

Mike

this was made with adobe illustrator, the same program used to draw my avatar.

[saridout]

The color coding is great, and you've gone better than the FSM also by adding color to the fusible links. But I see that you show two red links under the two covers instead of two brown ones. The labeling on the side of my 76 fusible link holders definitely says B, G, and two Br, and the manual says that B, G and Br are used also (page BE-6).

that's interesting. my reference for the fusible link colors was my own car. i recently replaced them too, and when i went to the nissan dealership and asked for a set for a 1976, i was given a black, green and two reds.

[Zed Head]

Well, maybe that's how the red/brown confusion started. Nissan is giving out new red for old brown. Was there wire size information with the links? I have seen information on the web that shows the red links as being bigger than 0.3 mm^2. The atlanticz page for instance (although their diagram shows orange for the 76) - http://www.atlanticz.ca/zclub/techtips/fusiblelinks/index.html . The red seems designed for a much bigger load than the brown, based on wire size alone. If so, the red won't give the protection the brown was designed for.

I will have to go down to Nissan and see what they have for links. Maybe they'll let me measure some wires.

Thanks for the reply and the work on the schematic. It would make a cool poster for a garage or den.

[saridout]

Was there wire size information with the links?

i threw out the packages a while back, but here's some info on courtesy nissan's site: http://www.courtesyparts.com/kb_search_result.php?chassis_id=59&keywords=fusible+link&Submit_Button=Go&cat=1

you could call them, they're fairly helpful.
