Captain Obvious

OK. I'll look through my pics and post a couple that would probably help. In the meantime, here's a couple pics of a pair of face cap pliers that I hovered off the web some time ago. These are made by Gator tools and are way to expensive to use once or twice. You local locksmith should have a pair of something similar: I made a crude pair out of a pair of slip joint pliers. I don't have any pics, but I'll take some and post what I did.

It appears to me that the location of the centerline of the steering shaft was moved up and to the left at the flange where it pokes through the firewall. That would make sense if you were trying to create more room for headers. And then, if you moved the centerline of the shaft up and to the left at the firewall end, you would then angle the steering column a little towards the right side of the car to catch the two mounting bolts. Since the two mounting bolts are designed to slide in the column, the mounting slide bushing on the right side will be closer to the top of the slot than the right side. Am I doing all that correctly? I've messed with my steering column (and others) way too many times now, and I've found the original flange at the firewall to be an inexact science. It's flimsy and easy to bend (probably by design for crash safety), and is mounted on a squishy indeterminate rubber gasket. The point of all that is.... I've never had a column install at the bottom and then had the top come right up against the mounting surface. I've always had to lift the column up to get the bolts started and often had to slide the mounting bushings fore or aft to get holes to line up. Again, I think those slidey bushings at the top are a safety feature to allow the column to push down in a crash instead of impaling the driver. I think it's designed to slip out of it's upper mounts if you compress the column enough (maybe 25mm or so?). Out of curiosity... Is that Silvermine firewall flange pieced together by welding a number of separate pieces together?

The issue for me is when my stones get that cold, my brain doesn't work so well. I can only imagine going through what those poor folks in the upper Midwest just dealt with. It's been unusually cold here near Philly, but I consider myself lucky compared to Chicago. I shouldn't complain. From what I hear, we're almost out of it. Love the pic of the cold double D's. Colder than a witches something... Can't remember how that's supposed to end.

Haha!! Yeah, once the ZX is ready, it'll be more appropriate! I just copied from the post above mine. Sorry!

I'm not sure I understand what the problem was with the original feed through column support flange. Do you have any pics that describe the issue you are (were?) having?

Which locks? I've taken them all apart and probably have pics that would help. Send me a PM?

I've done a number of locks now, and really the only PITA locks are the door locks because of that cover. It's called a "face cap", and there are special tools (face cap pliers) available to bend the lip up and take the cap off. After you remove the face cap, it's easy to rekey the locks and then crimp the cover back into place. I've done this a couple times now and actually made myself a crude version of face cap pliers and I can now do it relatively easily. The cap on the hatch locks is easy to get off, and the ignition and glove box locks don't have caps like that. dutchxcarguy's thing is a cheap workaround. Kinda like grinding your valve lash pads to fit instead of buying and installing the correct parts. I don't think I would endorse such a modification, but maybe only because I didn't think of it.

If I were to try to make filters, I would start with brass screen just like the stock filters. That way you could solder the seam just like the originals. And then you could also use some soft brass sheet to welt the ends and solder them in place as well. I don't know what hole size would be appropriate, but McMaster has brass screen with hole sizes down to six thousandths. >> https://www.mcmaster.com/brass-wire-cloth You can get a one square foot piece for about $7.50. Enough to go into production and supply filters for probably all of the flat-tops still on the road today!

Sweet. From what I've read, you won't be disappointed. And with the temperature at this time of year, I'm sure you'll be trying your new one out before I try mine. Just had to go a little bigger than mine, huh? Not the first time that's happened to me...

Look great. Hope they work as well as they look!! I've never found a source for replacement filters. I haven't looked hard, but in the little poking around I did, nothing turned up. Seems like they wouldn't be thaaaaat hard to make yourself. (Famous last words, right?)

the 2450 is a step down from the 3350, not up. The lens area goes up as the number goes up and the 3350 has the largest viewing area. The price difference between the two wasn't that much and I actually did consider getting the 3350, but I just don't think I would use it enough to justify the additional expense. The 3350 is aimed at people who weld for a living. I got the 2450 non-digital version. I actually did not want the digital version. Here I am an EE with embedded microprocessor experience and I prefer the non-digital version. Ever heard the joke about a room filled with engineers being asked if they would step onto a plane knowing their company wrote the software for it? Anyway, I'm just more comfortable with the older analog style there. If for no other reason.... With the turn of a knob, I can choose shade 9.5 instead of being locked into quantized choices of 9 and 10 with nothing in between. So to answer some of the questions... As you found, yes, all of them now have replaceable batteries, even the new version of your old 1840. I'm guessing they got too many complaints from people like you who ended up with dead batteries and changed the 1840 to include replaceable. Yes, the 1840 has two sensors while everything above that has four. And yes, there is some difference between the shades they can attain. Seems the higher end units (2450 and 3350) can go all the way down to shade 5. I don't really care about that though. If I'm using shade 5, it's because I'm using the oxy-acetylene rig and I don't use a helmet for that. I just use a number 5 full face shield. Not as claustrophobic or prone to lens fogging. So I don't really care about anything less than maybe shade 9 for low amp TIG work. Lastly the internal vs. external control thing... I'm not positive, but I believe the confusion about the 1840 is that the SHADE control is on the inside, but the GRIND/WELD control is on the outside. So you can switch between weld and grind without taking the helmet off, but if you want to change shades, you still have to take it off to do that. Again, I don't really care much. That feature is aimed at someone who is switching between welding and grinding all day and the seconds add to minutes and minutes matter. If I'm grinding, I'm switching to a cheap full face mask and not risking my new fancy expensive welding helmet with the grinding grit.

Absolutely. I've seen footage on TV.

Yeah, that natural color shade thing is one of the improvements in the one I just got. Lincoln calls it their "4C Technology", where I believe the "C" is Clarity. I ended up with the Viking 2450 and it's got that 4C lens. Four sensors and a little bigger window than your 1840: I haven't used it welding yet, but I did put it on and adjust the headgear. And verified that it switches to dark if I have the sensitivity set high and look at a bright light.

Forgot... So I assume the battery in Cody's HF helmet had welded tabs on the battery? They often produce two varieties of the small batteries, with or without welded tabs. The batteries themselves do not like heat, so if you are going to be soldering them into something, then you're supposed to use the ones with the tabs welded on. The tabs help isolate the soldering heat from and prevent it from getting into the batteries.

Yeah, the CR2430 is a lithium and not rechargeable. I wonder if you maybe just didn't have a couple years of built up grime and scratches on the arc sensors on your 1840 and that was obscuring the light into the ADF. I guess if I were in your position, I would give it one more try, and if there was even a peep of trouble I would toss it. That's where I was with my HF helmet. Worked most of the time. Except when it didn't.

Throttle shafts look cool. Make sure the butterfly plates fit in the slot and the retaining screws still fit the threads. I don't know how thick the coating is, or if it did a good job of getting into the nooks and crannies, but if there are any issues it would be easier to deal with before the shafts are back in the bodies.

Thanks for the dealer experience. I have heard (read it on the internet) that sometimes dealers got fed up with return complaints and just pulled the flat tops off and threw a set of round tops on instead. Easier than teaching their techs how to really really deal with the flat tops.

Yeah, that's just an unacceptable situation. Sounds like it was intermittent, and without figuring out definitively what the problem was (is), then you'll never trust it. That's where I was with my previous helmet, although I believe I can identify the issue as shadowing the (one and only) arc sensor. So is there a number on the internal battery? Can you tell if it's Ni-Cd, or Lithium? Reason I ask is that if it's Ni-Cd, then it might be rechargeable by the solar cell. But if its lithium, then it is not rechargeable.

I wouldn't be surprised if the dealers just pulled them off and replaced them with round tops as well. Sure would have saved a lot of time for their techs rather than having to understand and properly set-up the flat tops. I wonder. Anyone here have any dealer experience from back when these cars were still going to the dealers for service? What was the internal Nissan reputation of the flat tops?

My understanding is the solar does not charge the batteries, but acts as an "alternative" power source. In fact, I don't think lithium button cells are rechargeable at all. I think the screen will operate from whichever power source is higher, either solar or battery. I think the marketing descriptions usually say something like the solar cells "extend battery life". And they do that "extension" by providing an alternative power source. And the more you draw from the "alternate", the less you have to draw from the battery. So how is it that you made your original determination the helmet had failed? Did you draw a welding arc and it did not go dark? Or did it just stop going dark when you looked at the shop lights?

Nice work. Soon people will be clamoring all over each other to replace their round tops with flat tops. OK, maybe not. Do you really think that one diaphragm was folded over and pinched? I would expect a permanent hard crease if that were the case. Maybe it just shrank up a little and rolled under itself after you took the power valve apart. Doesn't really matter though as you're replacing both of them. And I think I mentioned before... Don't throw out your old bowl seals. You may find they work better than the new ones from the rebuild kits.

Well if the volts go all the way to the left, then there's a problem with the fusible links, or (hopefully not) something more serious going on with the wiring as Wayne mentioned. For the meantime though, I want to believe that the wiring inside the harness is OK at this point. So the last thing you said "red closest to the windshield" leaves me a little puzzled and makes it necessary to drop back again and do some verification about the link positions. Here's a pic I whipped up showing the correct fusible link positions and their basic functions. This pic is from my 1977 car and I have personally verified that it is correct for 77: I have indicated with the title of the pic that it applies to both 1977 and 78, but full disclosure... Even though I believe they are the same, I have never personally verified that 78 is the same as 77. So first thing to do would be to verify that your links are the same as mine and here's an easy way. One of the links goes to the headlights and nothing else. Nothing. Turn your headlights on and (after verifying that they are on) disconnect the link I have labeled "headlights". If the headlights go out, your 78 is the same as my 77. If the headlights don't go out then 77 and 78 are different.

Excellent. One other thing to double check... I've seen situations where the shank on the aftermarket lug nuts is a little too long and will actually bottom out on the rotor or drum face before the wheel is clamped tight. The problem occurs when the shank is longer than the wheel flange is thick. Yours are probably fine, but you should check that if you haven't already.

Well I'm not yet ready to condemn the ignition relay. That blinker test was just a quick and dirty way to do a rough test. If the blinkers DID work, then you can be pretty sure that the relay is working. But if the blinkers did NOT work, then there's a number of things that could cause that, including (but not limited to) a bad ignition relay. In fact, the same (largest) black fusible link that would cause the voltmeter to read zero (or four) would also cause the blinkers to not work as well. (It would also cause the dome light, map light, brake lights, horn, etc. to all fail.) So, which fusible link was it that you found to be bad? What color was it and what position on the car? And you never answered... When the problem is occurring, does the volt gauge read all the way to the left (like 4V)?

And for anyone getting ready to print out a big copy of revision "M" to hang on their garage wall.... Don't do that right now. There have been some recently discovered issues in Rev "M" and I believe there will be a Revision "N" coming out soon to fix those issues. So if you can hold off for a little bit, do so!
